100W 12V Monocrystalline Solar Panel

EV Charger AC Wall Mounted Charging Pile
EV Charger AC Wall Mounted Charging Pile
EV Charger AC Wall Mounted Charging Pile
  • Rated Power100W
  • Solar CellMonocrystalline
  • Open Circuit Voltage(Voc)24.5V
  • Short circuit current5.20A
  • Maximum current4.95A
  • Output Tolerance±3%
  • Temperature range-40℃~ +85℃
  • Weight15.06lbs
  • Size35.24×23.03×1.38 inches
  • Temperate coefficient of Isc(010+/-0.01)%/℃
  • Temperate coefficient of Voc-(0.38+/-0.01)%/℃
  • Temperature range-40℃~ +85℃
  • Size of extension cable4mm²(11AWG)/MC4 Connector
  • Length of extension cable 90cm(2.95ft)
  • Frame Aluminum alloy frame

This 100W 12V Monocrystalline Solar Panel is primarily used on off-grid situations that include RV, boat, sailboat, yacht, truck, cabin, camper, tent, trailer, golf cart. Daily output 500WH depends on the sunlight availability. Each solar panel comes with a pair of 35 inches cables. By-pass diodes are pre-installed in waterproof IP-65 rated junction box to minimize power drop caused by shade and ensure excellent performance in low-light environments. Withstand high wind (2400Pa) and snow loads (5400Pa), the surface is made up of 3.2mm low Iron glass, the monocrystalline modules are framed by 35mm width aluminum alloy, which is 2~5mm wider than the other’s.
